Yamaha Cygnus Ray ZR Drum
Yamaha India offers a new scooter, called Yamaha Cygnus Ray-ZR to the Indian market. It is made with rugged body metal, therefore it to be called a next-generation real boy's scooter. The scooter comes with drum brake and disk brake versions. It carries a host of advanced features such as 21-litre under seat storage, tubeless tyres and all new instrument panel. It offers a dynamic performance and decent mileage on the street roads as it is incorporated with the blue core powerhouse.
Yamaha Cygnus Ray ZR Drum Full Specifications
ENGINE SPECIFICATIONS
Displacement (cc) | 113 |
Engine Type | Four Stroke, BS IV Engine With BLUE CORE Technology |
No. of Cylinders | Single |
Valves Per Cylinder | Two |
Maximum Power | 7.1 BHP @ 7500 RPM |
Maximum Torque | 8.1 NM @ 5000 RPM |
Starter System | Self Start/Kick Start |
Fuel Delivery System | Carburettor |
Ignition | C.D.I (Capacitor Discharge Ignition) |
Cooling System | Air Cooling |
Gears | Automatic |
Clutch | Dry, Centrifugal |
Bore (mm) | 50 |
Stroke (mm) | 57.8 |
CHASSIS AND SUSPENSION
Chassis Type | V-belt automatic |
Front Suspension | Telescopic |
Rear Suspension | Unit Swing |
BRAKES
Front Brake | Mechanical Leading Trailing Drum Brake UBS |
Rear Brake | Mechanical Leading Trailing Drum Brake UBS |
TYRES AND WHEELS
Front Tyre Size | 90/100-10 |
Rear Tyre Size | 90/100-10 |
Wheel Size (inches) | 10 |
Tyres Types | Tubeless |
Wheel Type | Alloy |
ELECTRICALS
Battery | Maintenance free |
Tail Light | 12V,21/5W x 1 |
Dashboard | Analogue |
Headlamp | Halogen Bulb, AHO |
DIMENSIONS & WEIGHT
Length (mm) | 1820 |
Width (mm) | 690 |
Height (mm) | 1115 |
Weight (Kg) | 105 |
Ground Clearance (mm) | 130 |
Wheelbase (mm) | 1270 |
COLOR
Colors | Maverick Blue, Matte Green |
FUEL ECONOMY AND CAPACITY
Fuel Tank Capacity (litres) | 5.2 |
Fuel Consumption City (kmpl) | 50.00 |
Fuel Consumption Highway (kmpl) | 60.00 |
