TVS Jupiter ZX Disc
TVS Jupiter ZX Disc, is a top end variant of the Jupiter ZX, with disc brake option. Earlier, it was being sold with the Million R Edition badge that came into existence to celebrate the model's success journey of passing 1 Million customers in India. But recently, the bike maker has changed its name from the ZX Disc. Apart from this, the scooter is continue to offers features such as front disc brake, mobile charger, dual tone seat, chrome 3D Jupiter logo, beige panels and floor mat, etc. The available colours for the Jupiter ZX Disc are royal wine or ...
TVS Jupiter ZX Disc Full Specifications
ENGINE SPECIFICATIONS
Displacement (cc) | 109.7 |
Engine Type | 4 Stroke, OHC, BSIV Engine |
No. of Cylinders | Single |
Maximum Power | 7.88 BHP @ 7500 RPM |
Maximum Torque | 8NM @ 5500 RPM |
Starter System | Electric & Kick Start |
Ignition | Digital IDI with Ignition Map Technology |
Cooling System | Air Cooled |
Gears | Automatic |
Clutch | Primary CVT & Secondary Gear Box |
Bore (mm) | 54 |
Stroke (mm) | 49 |
CHASSIS AND SUSPENSION
Chassis Type | High Rigidity Underbone Type |
Front Suspension | 30 Advance Telescopic |
Rear Suspension | Gas Charged Mono Shock |
BRAKES
Front Brake | 220mm Disc |
Rear Brake | 130mm Drum |
TYRES AND WHEELS
Front Tyre Size | 90/90-12 |
Rear Tyre Size | 90/90-12 |
Wheel Size (inches) | 12 |
Tyres Types | Tubeless |
Wheel Type | Alloy |
ELECTRICALS
Battery | 12V, 5 Ah Flooded |
Tail Light | 12V, 2W/1.5W LED |
Dashboard | Analogue |
Headlamp | 12V, 35/35W Halogen (Multi-reflector Type) AHO |
DIMENSIONS & WEIGHT
Length (mm) | 1834 |
Width (mm) | 650 |
Height (mm) | 1115 |
Weight (Kg) | 108 |
Ground Clearance (mm) | 150 |
Wheelbase (mm) | 1275 |
COLOR
Colors | Royal Wine, Stallion Brown |
FUEL ECONOMY AND CAPACITY
Fuel Tank Capacity (litres) | 5 |
Reserve Fuel | 1.5 |
Fuel Consumption City (kmpl) | 45.00 |
Fuel Consumption Highway (kmpl) | 50.00 |
